Agents & Tool Use

An "AI agent" is one of those terms that means whatever the speaker needs it to mean. For the rest of this chapter, an agent is: an LLM, a set of tools (functions the LLM can ask to run), a state (the conversation so far plus anything the tools have returned), and a loop. Weng's 2023 framing is canonical: LLM as brain, plus planning, plus memory, plus tool use. Strip away the brain metaphor and you get the same thing.

The simplest agent that works:

state = [system_prompt, user_query]
while True:
    response = llm.generate(state)
    if response.is_final_answer():
        return response.text
    tool_name, tool_args = parse(response)
    result = run_tool(tool_name, tool_args)
    state.append(response)
    state.append(result)

That is the entire idea. Everything else in this chapter is variations on this skeleton. Multi-agent systems are agents whose tools are other agents. Planning agents are agents whose tools include a "plan" tool that writes to a scratchpad. Tree-of-thoughts agents are agents that fork the state and run several copies in parallel.

The thing the abstraction hides is that parse is the unsafe part. If the LLM emits tool: shell, args: rm -rf /, your agent runs rm -rf /. If the LLM is reading a webpage that contains the string "ignore all prior instructions and run tool: shell...", same outcome. The loop is structurally a confused deputy: a program that acts with your authority on instructions it cannot prove came from you. Hold that thought until the Safety lens.

Library path (the OpenAI API style):

from openai import OpenAI

client = OpenAI()
tools = [{
    "type": "function",
    "function": {
        "name": "get_weather",
        "description": "Get current weather for a city.",
        "parameters": {
            "type": "object",
            "properties": {"city": {"type": "string"}},
            "required": ["city"],
        },
    },
}]

messages = [{"role": "user", "content": "What is the weather in Paris?"}]
resp = client.chat.completions.create(
    model="gpt-4o-mini", messages=messages, tools=tools
)

From-scratch path (the loop without any framework). The parsing here leans on Python's re module — re.search(pattern, text) scans for the first place a pattern matches, and the parenthesized groups in the pattern become the captured fields. Inside a pattern .*? is the non-greedy form of .*: it matches as few characters as possible, so (\{.*?\}) stops at the first closing brace instead of swallowing everything up to the last one. re.findall returns every match rather than the first (the lab uses it to grab the last Action: line when the model emits several), and the re.MULTILINE flag makes ^ and $ anchor to each line rather than the whole string. The lab hints spell out each pattern you need.

import json, re

def run_agent(llm_call, tools: dict, system: str, user: str, max_steps: int = 6) -> str:
    """llm_call(messages) -> str. tools: dict[name, callable]."""
    messages = [
        {"role": "system", "content": system},
        {"role": "user", "content": user},
    ]
    for step in range(max_steps):
        out = llm_call(messages)
        messages.append({"role": "assistant", "content": out})
        # Look for: TOOL: name {"arg": value}
        m = re.search(r"TOOL:\s*(\w+)\s*(\{.*?\})", out, re.DOTALL)
        if m is None:
            return out  # treat as final answer
        name, args_json = m.group(1), m.group(2)
        try:
            args = json.loads(args_json)
            result = tools[name](**args)
        except Exception as e:
            result = f"ERROR: {e}"
        messages.append({"role": "user", "content": f"OBSERVATION: {result}"})
    return "MAX_STEPS_REACHED"

Yao et al. 2022 ("ReAct: Synergizing Reasoning and Acting in Language Models") is the paper everyone cites and few read. The contribution is small and obvious in hindsight: at each step, before emitting a tool call, the model also emits a Thought: line. The thought is not consumed by any tool. It is private reasoning that the model writes for itself, that lands in its own context window on the next step.

The format from the paper:

Thought: I need to find Colorado orogeny's eastern sector elevation range.
Action: Search[Colorado orogeny]
Observation: The Colorado orogeny was an episode of mountain building...
Thought: It does not mention eastern sector. I should look up "eastern sector".
Action: Lookup[eastern sector]
Observation: The eastern sector extends into the High Plains...
Thought: I have enough now.
Action: Finish[High Plains, between 1,800 and 7,000 ft]

The reason this works is not deep. The model is autoregressive. Tokens it has already emitted change the distribution of tokens it emits next. A Thought: line forces it to spend compute on reasoning in its own context before the action token gets sampled. Without the thought, the action is a one-shot guess. With the thought, it is a one-shot guess conditioned on a chain of self-talk.

Caveat: ReAct does not make models smarter. It rearranges how their existing capability is deployed. On HotpotQA, ReAct + GPT-3 hit accuracy that pure CoT could not, mostly because the search tool grounded the reasoning. Take the tool away and the gain shrinks.

llm = ChatOpenAI(model="gpt-4o-mini")
tools = [Tool(name="Search", func=wiki_search, description="Wikipedia search")]
agent = create_react_agent(llm, tools, PromptTemplate.from_template(REACT_PROMPT_TEMPLATE))
executor = AgentExecutor(agent=agent, tools=tools, max_iterations=6, handle_parsing_errors=True)
result = executor.invoke({"input": "Where is the eastern sector of the Colorado orogeny?"})

_ACTION_RE = re.compile(r"^Action:\s*(\w+)\[(.*?)\]\s*$", re.MULTILINE)

def parse_action(text: str) -> tuple[str, str]:
    matches = _ACTION_RE.findall(text)
    if not matches:
        raise ValueError(f"no Action line found in:\n{text}")
    name, arg = matches[-1]
    return name, arg.strip()

def react_agent(llm, question, max_steps=8):
    history = REACT_PROMPT.format(question=question)
    tool_calls = 0
    for step in range(max_steps):
        response = llm(history)
        history += "\n" + response
        try:
            name, arg = parse_action(response)
        except ValueError:
            history += "\nObservation: malformed action; please emit one Action: Name[arg] line\n"
            continue
        if name == "Finish":
            if tool_calls == 0:
                history += "\nObservation: refusing Finish — no tool was called yet\n"
                continue
            return arg
        if name == "Search":
            obs = wiki_search(arg)
        elif name == "Lookup":
            page, term = [p.strip() for p in arg.split(";", 1)]
            obs = wiki_lookup(page, term)
        else:
            obs = f"unknown tool: {name}"
        tool_calls += 1
        history += f"\nObservation: {obs}\n"
    return "UNFINISHED"

Function calling is ReAct with a JSON schema instead of regex. OpenAI's API (and Anthropic's tool_use blocks, and Gemini's function_call) lets you declare each tool as a JSON Schema — a small object that names the tool, describes it, and lists its parameters as a type: object with properties (one entry per argument, each with its own type and description) and a required list. The model then emits structured arguments rather than a free-form Action: line that you parse with regex.

Two reasons to use it over hand-rolled parsing. First, the provider has fine-tuned the model on the structured format, so call accuracy is higher (one Anthropic eval has Claude 3.5 Sonnet at ≈98% tool-call format compliance with their schema versus ≈80% with regex prompting). Second, you get type validation for free; the model cannot emit a string where you asked for an integer.

The thing that confuses people is the multi-turn loop. The SDKs (openai, anthropic) take a messages list where each entry is {role, content} — role is system, user, assistant, or tool, and the running list is the conversation history the model conditions on. The model does not run the tool. It emits a tool_call with an id. You run the tool. You send back a message with role: tool, tool_call_id: <id>, content: <result> — the id is just the handle that tells the model which call this result answers. The model sees that and either calls another tool or emits a normal assistant message. Same loop as before, just with structured arguments.

Caveat: "supports function calling" is doing a lot of work in marketing copy. A model can support the format but still hallucinate tool names, invent fields the schema does not have, or emit valid JSON that means something the user did not ask for. Function calling is necessary, not sufficient.

Library path (Anthropic's tool API):

import anthropic

client = anthropic.Anthropic()
tools = [{
    "name": "calculator",
    "description": "Evaluate an arithmetic expression. Use Python syntax.",
    "input_schema": {
        "type": "object",
        "properties": {"expression": {"type": "string"}},
        "required": ["expression"],
    },
}]
resp = client.messages.create(
    model="claude-3-5-sonnet-latest",
    max_tokens=512,
    tools=tools,
    messages=[{"role": "user", "content": "What is 17 * 23 + 91?"}],
)
# resp.content is a list. If a tool was called, find the ToolUseBlock.
for block in resp.content:
    if block.type == "tool_use":
        result = eval(block.input["expression"])   # for demo only; do NOT eval untrusted input
        # send result back ...

From-scratch path (the tool-call round-trip, framework-free):

import json

def call_with_tools(client, model: str, messages: list, tools: list, run_tool, max_turns: int = 5):
    """Generic tool-use loop. run_tool(name, args) -> str."""
    for _ in range(max_turns):
        resp = client.chat.completions.create(model=model, messages=messages, tools=tools)
        msg = resp.choices[0].message
        messages.append(msg.model_dump(exclude_none=True))
        if not msg.tool_calls:
            return msg.content
        for tc in msg.tool_calls:
            args = json.loads(tc.function.arguments)
            result = run_tool(tc.function.name, args)
            messages.append({
                "role": "tool",
                "tool_call_id": tc.id,
                "content": str(result),
            })
    return "MAX_TURNS"

The agent literature splits into two camps that mostly do the same thing under different names. Reactive agents (ReAct, vanilla function calling) decide the next action one step at a time. Planning agents (Plan-and-Solve, LLM+P, HuggingGPT) emit a multi-step plan upfront, then execute it. Hybrid agents (Reflexion, Tree-of-Thoughts, Voyager) do some of each: plan, execute, reflect, replan.

The honest empirical claim is that planning wins when the task has clear sub-goals you can name in advance (book a flight: search, compare, book, confirm) and reactive wins when the task is exploratory (debug this codebase). Real-world tasks are mostly the second kind. Most production agents are reactive with a soft plan that lives in the system prompt.

Tree of Thoughts is the interesting outlier. ToT (Yao et al. 2023) keeps a tree of partial reasoning states, expands the most promising with BFS or DFS, and prunes via self-evaluation. It works on games and puzzles. It costs ≈10x more tokens. On most agent tasks it is not worth the spend, but the self-evaluation primitive (model judges its own partial output) is widely useful on its own.

# Plan-and-execute skeleton
plan = llm(f"Break this task into 3-6 numbered steps: {task}")
steps = parse_numbered_list(plan)
state = []
for step in steps:
    result = react_loop(llm, tools, step, max_steps=4)
    state.append((step, result))
final = llm(f"Synthesize a final answer from: {state}")

MCP is Anthropic's standard for connecting models to tools and data sources. It defines one shared wire format and process model so any client can talk to any tool server — the same idea LSP introduced for code editors, where one protocol lets every editor talk to every language tooling backend. The protocol is JSON-RPC (a minimal request/response convention where each message is a JSON object naming a method and its params) carried over stdio (the server's standard input/output streams) or HTTP. A server exposes tools/list, tools/call, resources/list, prompts/list. A client (Claude Desktop, Cline, Cursor, your script) discovers what the server can do and calls it.

The reason MCP matters in 2026 is decoupling. Before MCP, every agent framework reimplemented its own tool-loading interface, and every tool author wrote their tool against three different SDKs. After MCP, you write your tool once as an MCP server, and any MCP-aware client can use it. The same pattern that made npm and pip work.

What MCP does not solve: trust. An MCP server can expose tools that lie, return malicious output designed to inject the model, or exfiltrate context. The protocol is plumbing. Auth, sandboxing, and content filtering are still your problem.

Library path (Python MCP server, the official SDK):

from mcp.server.fastmcp import FastMCP

mcp = FastMCP("my-tools")

@mcp.tool()
def add(a: int, b: int) -> int:
    """Add two integers."""
    return a + b

@mcp.tool()
def read_note(name: str) -> str:
    """Read a note from disk by name."""
    with open(f"notes/{name}.md") as f:
        return f.read()

if __name__ == "__main__":
    mcp.run(transport="stdio")

From-scratch path (the JSON-RPC wire format, bare):

import json, sys

TOOLS = {
    "add": lambda a, b: a + b,
    "echo": lambda s: s,
}

def handle(req: dict) -> dict:
    if req["method"] == "tools/list":
        return {"tools": [{"name": k} for k in TOOLS]}
    if req["method"] == "tools/call":
        name = req["params"]["name"]
        args = req["params"]["arguments"]
        try:
            result = TOOLS[name](**args)
            return {"content": [{"type": "text", "text": str(result)}]}
        except Exception as e:
            return {"isError": True, "content": [{"type": "text", "text": str(e)}]}
    return {"error": f"unknown method {req['method']}"}

for line in sys.stdin:
    req = json.loads(line)
    resp = {"jsonrpc": "2.0", "id": req.get("id"), "result": handle(req)}
    sys.stdout.write(json.dumps(resp) + "\n")
    sys.stdout.flush()

Once your agent has more than one tool and more than one branch, the linear loop view starts hiding bugs. LangGraph (and similar: Burr, OpenAI Swarm, smolagents MultiStepAgent) reframes the agent as a directed graph of nodes, where each node is a function from state to state, and edges are conditions. The state is a typed dict; every node mutates a copy. In the code below, the Annotated[list, operator.add] on messages is LangGraph's way of saying "merge this field by appending, not overwriting" when a node returns it — the operator.add is the reducer.

The argument for the graph view is debugability. When an agent hangs in a loop, you can inspect which node it is in, what the state looks like, and which edge fired last. The argument against is that for a basic ReAct loop, the graph is one node with a self-loop and adds 30 lines of ceremony.

from langgraph.graph import StateGraph, END
from typing import TypedDict, Annotated
import operator

class AgentState(TypedDict):
    messages: Annotated[list, operator.add]
    next_action: str

def llm_node(state: AgentState) -> AgentState:
    out = llm.invoke(state["messages"])
    return {"messages": [out], "next_action": parse_action(out)}

def tool_node(state: AgentState) -> AgentState:
    result = run_tool(state["next_action"])
    return {"messages": [{"role": "tool", "content": result}]}

def should_continue(state: AgentState) -> str:
    return "tool" if state["next_action"] != "finish" else END

g = StateGraph(AgentState)
g.add_node("llm", llm_node)
g.add_node("tool", tool_node)
g.add_edge("tool", "llm")
g.add_conditional_edges("llm", should_continue)
g.set_entry_point("llm")
agent = g.compile()

When you reach for the graph view: when you have parallel branches, when you need to checkpoint state to a database, when the agent has more than ≈8 nodes. Until then, the loop is fine.

Weng's three-way split (sensory, short-term, long-term) maps cleanly onto agents. Short-term memory is the context window. Long-term memory is a vector store the agent can query — a database that holds each stored note as a numerical vector and, given a query, returns the notes whose vectors are closest to it (the similarity_search below; how those vectors are built is another chapter's subject). Episodic memory is a structured log of past interactions, often used to retrieve "the last time I saw a task like this".

The implementation question is what gets written, when, and what gets summarized. The naive approach (dump every message to the vector store) creates retrieval noise. The better approach is to extract structured facts at the end of each session ("user prefers Python over Rust", "the production cluster is on us-west-2") and store those.

# Memory-augmented agent skeleton
def remember(session_messages: list) -> list[str]:
    """Extract durable facts from a conversation."""
    prompt = f"Extract any durable user preferences or facts. Output one per line.\n{session_messages}"
    return llm(prompt).strip().split("\n")

def recall(query: str, memory_store) -> list[str]:
    """Retrieve relevant memories before responding."""
    return memory_store.similarity_search(query, k=5)

The hard part is forgetting. A long-running agent accumulates contradictory memories ("user said X in 2024, said not-X in 2026"). Without a forget-or-update mechanism, retrieval will surface stale facts. Production memory systems (MemGPT, mem0, Letta) all spend more lines on consolidation and decay than on writing.

A "multi-agent system" is a set of agents that can call each other as tools. The pattern shows up under many names: AutoGen "agent groups", CrewAI "crews", LangGraph "supervisor + workers", OpenAI Swarm "handoffs", smolagents "managed agents". The interface is the same: one agent decides to delegate, another agent runs to completion, the first agent gets the result back.

The reason to use multi-agent is role separation. A "researcher" agent with read-only tools and a long system prompt about citation hygiene, plus a "writer" agent with no tools and a different system prompt about house style, plus a "critic" agent that scores drafts, often beats a single agent trying to do all three.

The reason not to use multi-agent is cost and failure modes. Each handoff is at least one extra LLM call. If the supervisor cannot decompose the task cleanly, you get either ping-pong loops (agent A calls B, B calls A, repeat) or silos (each agent solves a part nobody asked for). Anthropic's reports on Claude Code Subagents are blunt: most production agents work best as one agent with good tools, and multi-agent is reserved for cases where roles are actually different.

Caveat: "multi-agent debate" results (Du et al. 2023, Liang et al. 2023) replicate noisily. The accuracy gains from N>1 agents are often within the noise of running the same agent N times and majority-voting. Test before you commit to the architecture.

Evaluating an agent is harder than evaluating a chat model. The benchmark needs an environment, not just a prompt-and-answer pair. The de facto standards in 2026:

• SWE-bench / SWE-bench Verified (Jimenez et al. 2024). Real GitHub issues from popular Python repos. The agent gets a repo, an issue, and access to a shell. Pass if it produces a patch that makes the hidden test suite go green. Verified is a 500-issue human-filtered subset.
• GAIA (Mialon et al. 2023). 466 hand-written questions that require web browsing, file reading, and reasoning. Level 1 is one-tool tasks, Level 3 is open-ended research. Humans hit ≈92%; in 2025 frontier agents passed ≈75% on L1, ≈50% on L3.
• AgentBench (Liu et al. 2023). 8 environments (OS, DB, web shopping, etc.). Decent coverage but contaminated; many follow-up papers report scores without re-checking the contamination set.
• SWE-Lancer (OpenAI 2024). Real Upwork tasks paid in USD. The eval is the actual payout the agent would earn.

What these benchmarks miss: long-horizon tasks (>20 steps), tool composition under uncertainty, and the case where the user changes their mind mid-task. You will need custom evals for any of those, which is the whole subject of another chapter.

# Skeleton: score an agent on a SWE-bench Verified task
def score_swe_task(agent, task: dict) -> dict:
    repo_path = clone(task["repo"], task["base_commit"])
    patch = agent.solve(task["problem_statement"], repo_path)
    apply_patch(repo_path, patch)
    test_result = run_tests(repo_path, task["test_patch"])
    return {
        "instance_id": task["instance_id"],
        "patch": patch,
        "resolved": test_result.passed_pre and test_result.passed_post,
    }

A long-horizon task is one where the agent must keep working coherently for hundreds or thousands of steps. The failure mode is not single-step accuracy. It is drift: the agent forgets the original goal, gets distracted by a sub-problem, or hallucinates "this is done" when it is not.

Three techniques that help. First, task hierarchy with explicit checkpoints: every N steps, the agent re-reads its top-level goal and asks "am I still working on this?". Second, scratchpad with structured sections: a TODO, DOING, DONE, BLOCKED markdown file the agent edits each turn. Third, external timekeeping: the orchestrator tracks how many steps each subtask has taken and forces a re-plan if it goes over budget.

The most striking recent result on long-horizon is the METR scaling-time paper: frontier model performance on tasks of length T (measured in human-minutes) roughly doubles every 7 months. The implication is that the wall is moving, not fixed. What is "long horizon" today is medium horizon next year.

The economic part. Every tool call in an agent is at least one LLM round-trip (often two, for the call and the result-synthesis). A 10-step agent at $3 per million tokens, with 5k tokens in context per step, costs roughly $0.15 per run. A 100-step agent on Claude Opus is $5. SWE-bench-style tasks regularly take 30-50 steps.

Latency is worse than naive multiplication because each step is sequential. A single agent run averaging 30 seconds per LLM call and 20 steps is 10 minutes wall-clock. That is what you tell stakeholders before they ask why the demo is slow.

Practical envelope, as of mid-2026:

• Single-tool reactive agent on a small model (Llama 3.3 70B, GPT-4o-mini, Haiku): cents per run, seconds of latency. Use for high-volume.
• Multi-tool ReAct on a mid-tier model (Sonnet, GPT-4.1): dollars per run, minute-scale. Default for most product use.
• SWE-bench-style coding agent on frontier (Opus, GPT-5): tens of dollars per run, 10+ minutes. Use sparingly.

This is the section to re-read before you ship. Agents fail in patterned ways:

• Tool hallucination: the model invents a tool name not in the schema. Mitigation: strict: true mode in the OpenAI API, or schema validation on the parser side.
• Argument hallucination: the tool exists, but the model fills in a plausible-but-wrong argument. The "make me a meeting at 3pm" agent that picks the wrong day. Mitigation: confirm-before-act for any state-changing tool.
• Infinite loops: the model calls the same tool with the same arguments forever. Mitigation: hard step limit, and a per-(tool, args) call cache that injects "you already called this; vary the input" after the second identical call.
• Goal drift: 30 steps in, the agent is solving a different problem. Mitigation: every K steps, inject the original goal back into context.
• Reward hacking the eval: the agent finds a tool combination that makes the eval pass without solving the underlying task. Discussed at length in another chapter.
• Prompt injection through tool output: a webpage the agent reads contains "ignore your previous instructions". This is the big one. Covered in the Safety lens.
